ACOG® 3.5x35 scope with Red Chevron BAC Reticle- The ranging reticle is calibrated for 5.56 (.223 cal) flat-top rifles to 800 meters. The chevron reticle is designed to be zeroed using the tip at 100 meters. The width of the chevron at the base is 5.53 MOA which is at 19” at 300 meters. This allows range estimation for silhouette targets.
FEATURES:
SPECS:
Length x Width x Height: 8 in x 2.1 in x 2.9 in (203.2mm x 53.34mm x 73.66mm)
Weight: 17.6 oz. (498.95g)
Magnification: 3.5x
Objective Size: 35mm
Reticle Pattern: Chevron
Day Reticle Color: Red
Night Reticle Color: Red
Bullet Drop Compensating (BDC): Yes
Caliber: .223 / 5.56
Bindon Aiming Concept™ (BAC): Yes
Illumination Source: Fiber Optics & Tritium
Power Source: Fiber Optics & Tritium
Adjustment: ½ MOA per click
Eye Relief: 2.39 in. (60.71mm)
Exit Pupil: 0.39 in. (9.91mm)
Field of View (degrees): 5.5°
Field of View (feet): 28.9 ft. @ 100 yds. (9.63m @ 100m)
Mount: Flattop Thumbscrew Mount (TA51)
Housing Material: Forged Aluminum
Finish: Matte Black
INCLUDES:
Thumbscrew Flattop Adapter (TA51)
3.5x35 Scopecoat (TA63)
LENSPEN (TA56)
Lanyard Assembly for Adjuster Caps (TA71E)
Trijicon Logo Sticker (PR15)
ACOG BAC Manual
Warranty Card
3.5x35 Scopecoat (TA63)
LENSPEN (TA56)
Lanyard Assembly for Adjuster Caps (TA71E)
Trijicon Logo Sticker (PR15)
ACOG BAC Manual
Warranty Card
- Manufacturer Part Number:
- TA11F
