ACOG® 3.5x35 LED RIFLESCOPE - .223 / 5.56 BDC GREEN CHEVRON RETICLE, THUMBSCREW MOUNT, LED ILLUMINATED

TRIJICON

MSRP: $1,642.00
Sale: $1,209.95
(No reviews yet) Write a Review
UPC:
719307320963

From the legendary ACOG® family of products, the LED ACOG is the first to offer user-selectable brightness controls. Users can select from six adjustable brightness levels with an "off" between each setting, allowing the operator to determine how much to illuminate the reticle - even in transitional lighting. Powered by a single AA battery, the LED ACOG can run for over 12,000 continuous hours (on setting #4). Like all ACOG models, it is forged from rugged 7075-T6 aircraft-aluminum, resulting in a nearly indestructible sighting system and electronics that offer outstanding reliability. Users can select multiple bullet drop compensating and ranging reticle options. Fully night vision device compatible, the Trijicon 3.5x35 LED ACOG is also compatible with most other 3.5x35 ACOG accessories available.

FEATURES:

SPECS:

Length x Width x Height: 8 in x 3 in x 2.6 in (203.2mm x 76.2mm x 66.04mm)
Weight: 20.8 oz. (589.67g)
Magnification: 3.5x
Objective Size: 35mm
Reticle Pattern: Chevron
Day Reticle Color: Green
Night Reticle Color: Green
Bullet Drop Compensating (BDC): Yes
Caliber: .223 / 5.56
Bindon Aiming Concept™ (BAC): Yes
Illumination Source: LED
Illumination Settings: 6
Power Source: AA Lithium or Alkaline Battery
Battery Life: Over 12,000 hours on setting #4 using supplied alkaline battery at 21 deg C (70 deg F)
Adjustment: ½ MOA per click
Adjustment Range: 40 MOA Total Travel
Eye Relief: 2.4 in. (60.96mm)
Exit Pupil: 0.39 in. (9.91mm)
Field of View (degrees): 5.5°
Field of View (feet): 28.9 ft. @ 100 yds. (9.63m @ 100m)
Mount: Flattop Thumbscrew Mount (TA51)
Housing Material: Forged Aluminum
Finish: Matte Black

INCLUDES:
Thumbscrew Flattop Adapter (TA51)
AA Battery
LENSPEN (TA56)
Lanyard Assembly for Adjuster Caps (TA71E)
Lanyard Assembly for Battery Cap
Trijicon Logo Sticker (PR15)
LED ACOG Manual
Warranty Card
Manufacturer Part Number:
TA110-C-100492
